CNC Spindle Encoder
The spindle encoder is mainly applied to CNC machines.The sychronis pulses from encoder is collected by CNC system and then the feeding data of tools are sent to servo motor to perform the motion.
- Magnetic ring Encoder
The magnetic ring encoder, based on advanced magneto-electric induction technology, is widely used in automation control and measurement.It is mounted to CNC spindle directly without synchronous wheel transmission.
Features:Non-contact sensing technology between readhead and ring;multiple rings demensions for wide applications;could be used in harsh environment;IP 68 for readhead.
| Picture | Model | Outer Dia. （mm） |
Max Hole Dia. （mm） |
Resolution |
Output Signal | Operating Voltage | Max Mechanical Speed（r/min） | pdf Download | ||||
 |
RTD163 | 163mm | 135mm | 128-16384 ppr | L | 5V | 35000 r/min |  |
||||
 |
RTD122 | 122mm | 90mm | 128-16384 ppr | L | 5V | 35000 r/min | |
||||
 |
RTD115 | 115mm | 85mm | 128-16384 ppr | L | 5V | 35000 r/min | |
||||
 |
RTD82 | 82mm | 60mm | 128-16384 ppr | L | 5V | 35000 r/min | |
||||
Output Signal Definition:
C:open collector;E:voltage;F:pushpull;L:line driver; A:wide voltage line driver
